Dell UNIVERSAL DOCK UD22 USB-C, 130W 210-BEYV

Ports & interfaces

Connectivity technology

Docking

Host interface

Thunderbolt

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

4

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

2

PowerShare

Yes

Number of USB ports with PowerShare support

2

USB Power Delivery (USB PD)

Yes

USB Power Delivery up to

96 W

USB Power Delivery revision

3.0

HDMI ports quantity

1

HDMI version

2.0

DisplayPorts quantity

2

DisplayPort version

1.4

Microphone in

No

USB Type-C DisplayPort Alternate Mode

Yes

DC-in jack

Yes

Network

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

Ethernet LAN data rates

10,100,1000 Mbit/s

Performance

Card reader integrated

No

Maximum digital resolution

5120 x 2880 pixels

Cable lock slot

Yes

Cable lock slot type

Kensington

VESA mounting

Yes

Maximum VESA mount

100 x 100 mm

Product colour

Black

LED indicators

Yes

Power

Power source type

DC

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Power supply

130 W

Input current

2.5 A

Output current

6.67 A

Output voltage

19.5 V

Software

Windows operating systems supported

Windows 10, Windows 11

Mac operating systems supported

MacOS

Linux operating systems supported

Ubuntu 20.04 LTS

Other operating systems supported

ChromeOS

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

10 - 80%

Storage relative humidity (H-H)

5 - 90%

Weight & dimensions

Width

76 mm

Depth

166 mm

Height

32 mm

Weight

416 g

Packaging content

Quick start guide

Yes

AC adapter included

Yes

Cables included

USB Type-C
